SIC JBS

SIC JBS

具有市面上现有碳化硅二极管的先进特性（无反向恢复时间、耐高温）

产品申请表
方案设计
  • 650V
  • 1200V
  • 4A
  • 10A
  • 15A
  • 20A
  • 30A
  • 40A
  • 1.35V
  • 1.4V
  • 1.38V
  • 1.37V
  • TO-220-2L
  • TO-263-2L
  • TO-247-2L
  • TO-247-3L
  • Industrial
  • Automotive
Product SKU DataSheet Blocking Voltage Current Rating Maximum Continuous Current (If at 135℃) Qc_Typ. Vf_Typ. at 25℃ Package Generation Qualification Status
S1D004065A 650V 4A 7A 9.5nC 1.35V TO-220-2L G1 Industrial Sample
S1D010065A 650V 10A 16A 26nC 1.35V TO-220-2L G1 Industrial Sample
S1D010065G 650V 10A 14A 26nC 1.35V TO-263-2L G1 Industrial Sample
S1D015120A 1200V 15A 22A 82nC 1.4V TO-220-2L G1 Automotive Active
S1D015120C 1200V 15A 22A 82nC 1.4V TO-247-2L G1 Automotive Active
S1D020120C 1200V 20A 29A 110nC 1.38V TO-247-2L G1 Automotive Active
S1D020120G 1200V 20A 35A 114nC 1.4V TO-263-2L G1 Automotive Active
S1D030120C 1200V 30A 43A 157nC 1.4V TO-247-2L G1 Automotive Active
S1D030120D 1200V 30A 23/46A 81nC 1.37V TO-247-3L G1 Automotive Active
S1D040120D 1200V 40A 31/60A 110nC 1.38V TO-247-3L G1 Automotive Active
